520315 Macs USA Double Stud Tie Down Anchor Plate Assembly - 4 Pack
larger imageMove mouse over the image to magnify

520315 Macs USA Double Stud Tie Down Anchor Plate Assembly - 4 Pack

520315 Macs USA Double Stud Tie Down Anchor Plate Assembly - 4 Pack
NZ $224.00
Incl. GST
520315 Macs USA Double Stud Tie Down Anchor Plate Assembly - 4 Pack

Product Description

Installing the Double Stud Anchor Assembly
Installing the Double Stud Anchor Assembly

New surface mounted anchor plates for a robust tie-down locations that don't need adjustment—perfect for vehicle tie-down points

Our Double Stud Anchor Plate Assemblies let you add tie-down points virtually anywhere, but are designed specifically for our higher load capacity double stud fittings, such as the included VT-2000 Double Stud Tie-Down Ring. This combination offers nearly twice the holding power (5,000lb Minimum Breaking Strength) as our Single Stud Anchor Plate Assemblies. This is a great solution when securing a heavy loads where a full length track system is not desired.

Fixing Kit

Custom Look Without the Cost

Each anchor plate provides a sleek, finished look, since it is precision milled using the same profile as our Series 3 VersaTie track. When the fittings are removed, the anchor plates are smooth and unobtrusive. This is particularly beneficial for multi-use trailers. When not using for hauling a vehicle, you can even add multiple VT-1000 Single Stud Tie-Down Rings for additional hard points to secure various cargo. And the Double Stud Anchor Assembly 4-pack saves you money!

Built to Withstand the Elements

For long-lasting performance, each anchor plate is manufactured from rugged aircraft-grade aluminum. The mild steel backing plates are zinc-dipped to inhibit corrosion, then press-fit with stainless steel swage nuts. Stainless steel screws are provided to attach each assembly to your structure to ensure years of trouble-free service.

Easy Installation

Each Double Stud Anchor Plate is pre-drilled with three countersunk holes. After drilling matching holes in the main structure, simply insert the screws through the anchor plate and structure and tighten into the threads of the backing plate.

Made in the USA


Product Highlights

  • Add a heavy-duty tie down points right where you need them—perfect for securing a vehicle
  • Tested to 5000lb Minimum Breaking Strength in vertical pull
  • Designed to take advantage of the additional strength of double stud tie-down fittings, such as the VT-2000 Double Stud Tie-Down Ring
  • Provides smooth, unobtrusive surface when fittings are removed
  • The perfect complement to our VersaTie Track System
  • Made in the USA!

What's Included

  • (4) Aluminum Double Stud Anchor Plates
  • (4) Zinc-dipped Mild Steel Threaded Backing Plates
  • (4)  310002 Double Stud Tie-Down Rings
  • (12) 1/4" UNC x 1 1/2" Countersunk Stainless Steel Machine Screws -provides for 15mm thick deck. (1 1/2" screws also available)
Weight 2Kg
